Product Details:
|
| Product Model: | ZP07 | Gas Detection: | Formaldehyde, Benzene, Carbon Monoxide, Hydrogen, Alcohol, Ammonia, Cigarette Smoke, Essence, Etc. |
|---|---|---|---|
| Physical Interface: | XH2.54-4P Terminal Socket | Output Data: | 0～10 Pollution Signal |
| Highlight: | Ten Grade Air quality module,ZP07 Air quality module,High Sensitivity Air quality module |
||
ZP07 Air quality module Ten Grade High Sensitivity
ZP07-MP503-10 grade air quality module adopts advanced chip thick film semiconductor gas sensor. The sensor has extremely high sensitivity to organic volatile gases such as formaldehyde, benzene, carbon monoxide, ammonia, hydrogen, alcohol, cigarette smoke, and essence. The module has been aged, debugged, calibrated and calibrated, and has good consistency and high sensitivity.
Specifications:
| Working voltage | 5.0±0.2V DC (no voltage reverse polarity protection) |
| Output data type | Level pulse signal (built-in 200Ω protection resistor) |
| Working current | ≤60mA |
| Warm-up time | ≤3 minutes |
| Response time | ≤20 seconds |
| Recovery time | ≤60 seconds |
| Working temperature | 0～50℃ |
| Working humidity | ≤95%RH |
| Storage temperature | -20～60℃ |
| Storage humidity | ≤60%RH |
| Dimensions | 24*20*16mm (L*W*H) |
| Weight | ≤20g |
| Sensitivity attenuation | ≤1%/year |
