Product Details:
|
| Heating Voltage: | VH 2.5V±0.1V ACorDC (high Temperature) | Load Resistance: | RL Adjustable |
|---|---|---|---|
| Heating Time: | TL 60s±1s (high Temperature), 90s±1s (low Temperature) | Heating Resistance: | RH 80Ω±20Ω (room Temperature) |
| Highlight: | MEMS CO Gas Sensor,GM 702B Gas Sensor,GM 702B CO Sensor |
||
RL Adjustable MEMS CO Gas Sensor GM 702B For Industrial CO Gas Alarms
MEMS CO Sensor GM-702B For Industrial CO Gas Alarms
Features:
MEMS carbon monoxide gas sensor uses MEMS process to fabricate micro-hot plates on Si substrate. The gas-sensitive material used is metal oxide semiconductor material with low conductivity in clean air. When the detected gas exists in the ambient air, the conductivity of the sensor changes. The higher the concentration of the gas, the higher the conductivity of the sensor. A simple circuit is used to convert the change in conductivity into an output signal corresponding to the concentration of the gas.
Household CO gas leakage alarm, industrial CO gas alarm and portable CO gas detector, etc
Adopt MEMS process, strong structure, high sensitivity to CO
Small size, low power consumption, high sensitivity, fast response recovery
The driving circuit is simple, stable and long life
Specifications:
| Product type | MEMS carbon monoxide gas sensor |
| Standard package | ceramic package |
| Detection gas | carbon monoxide Detection concentration :5ppm-5000ppm(CO) |
| Loop voltage | Vc ≤24V DC |
