Product Details:
|
| Product Type: | Humidity Sensors | Unit Weight: | 11.688 G |
|---|---|---|---|
| Accuracy (best Fit Straight Line): | -3.5~+3.5%RH | Hysteresis: | 3%RH |
| Highlight: | HIH-4602,Integral Thermistor Humidity Sensor,HIH-4602 Thermal Temperature Sensor |
||
HIH-4602-C Humidity Sensors Contains An Integral Thermistor
FEATURES
• Near linear voltage output vs %RH
• Laser-trimmed interchangeability
• Enhanced accuracy, fast response
• Chemically resistant
• Stable, low drift performance
• Built-in static protection
• Often ideal for dew point and absolute moisture
measurements
• TO-5 housing
POTENTIAL APPLICATIONS
• Refrigeration
• Drying
• Meteorology
• Battery-powered systems
• OEM (Original Equipment Manufacturer) assemblies
HIH-4602-A/C Series Relative Humidity (RH) sensors combine
both relative humidity and temperature sensing in a TO-5
housing with a hydrophobic sintered stainless steel filter.
The laser-trimmed, thermoset polymer capacitive sensing
elements have on-chip integrated signal conditioning.
The temperature sensor is thermally connected with the RH
sensor making the HIH-4602-A/C often ideal for measuring
dew point and other absolute moisture terms
Datasheet:
| RH range | 0 % to 100 % |
| Mounting Style | Through Hole |
| Output Type | Analog |
| Supply Voltage - Min | 4 V |
| Supply Voltage - Maximum | 5.8 V |
| Minimum operating temperature | - 40 C |
| Maximum operating temperature | + 85 C |
| RH accuracy | +/- 3.5 % |
| Package / Case | TO-5 |
