Product Details:
|
| Supply Voltage: | 3.8 | Supply Voltage: | Min: 3.8 V |
|---|---|---|---|
| Unit Weight: | 120 Mg | ||
| Highlight: | SS443A,Board Interface Hall IC Type Sensor,SS443A Mass Flow Rate Sensor |
||
SS443A Board Interface Hall Effect/Magnetic Sensor Flow Rate Sensing
FEATURES
• Quad Hall IC design minimizes mechanical stress effects
• Temperature-compensated magnetics help provide stable
operation over a wide temperature range of -40°C to 150°C
[-40°F to 302°F]
• Broad, inclusive supply voltage capability from 3.8 Vdc to
30 Vdc for application flexibility
• Digital, open collector sinking output for easy interfacing
with a variety of common electronic circuits
• High sensitivity versions available for potential applications
requiring high accuracy or wide gaps
• Bipolar, latching or unipolar magnetics
POTENTIAL APPLICATIONS
• Industrial: Speed and RPM (revolutions per minute) sensing,
tachometer, counter pickup, flow-rate sensing, brushless dc
(direct current) motor commutation, motor and fan control,
robotics control
• Transportation: Speed and RPM (revolutions per minute)
sensing, tachometer, counter pickup, motor and fan control,
electric window lift, convertible roof position
• Medical: Motor assemblies, medication dispensing control
| Type | Unipolar |
| Operating supply current | 10 mA |
| Maximum output current | 20 mA |
| Operating supply voltage | 12 V |
| Minimum operating temperature | - 40 C |
| Maximum operating temperature | + 150 C |
| Mounting Style | Through Hole |
| Package/Case | TO-92-Flat-3 |
