Product Details:
|
| Type: | Bipolar | Operating Supply Current: | 10 A |
|---|---|---|---|
| Maximum Output Current: | 20 MA | Operating Supply Voltage: | 24 V |
| Highlight: | SS41F Hall Effect Sensor,SS41G Digital Hall Effect Sensor,Linear Magnetic Hall Sensor |
||
SS41F Board Interface Hall Effect Magnetic Sensor TO92 Package
The SS41F and SS41G are small, versatile digital Hall-effect devices that are operated by the magnetic field from a permanent magnet or an electromagnet, and are designed to respond to alternating North and South poles. A built-in regulator provides enhanced stability of operation
over 4.5 Vdc to 24 Vdc supply voltage range, and internal circuitry is designed to prevent sensor damage in case the supply voltage polarity is accidentally reversed. The open-collector sinking output voltage is easily interfaced with a wide variety of electronic circuits.
Datasheet:
| Minimum operating temperature | - 40 C |
| Maximum operating temperature | + 150 |
| Mounting Style | Through Hole |
| Package/Case | TO-92-Flat-3 |
| Output voltage | 0.4 V |
| Supply voltage - max | 24 V |
| Supply Voltage - Min | 4.5 V |
| Unit weight | 120 mg |
