Product Details:
|
Product Category: | Board Interface Hall Effect/Magnetic Sensors | Type: | Ratiometric |
---|---|---|---|
Operating Supply Current: | 8.7 MA | Maximum Output Current: | 10 MA |
Highlight: | SS496B Hall Effect Sensor,Ratiometric Hall Effect Sensor,Ratiometric Magnetic Field Sensor |
SS496B Board Interface Hall Effect Ratiometric Magnetic Field Sensor
FEATURES
• Linear output for circuit design flexibility
• Quad-Hall IC design minimizes mechanical stress effects
• Responds to either positive or negative Gauss
• Uses 7 mA at 5 Vdc for energy efficiency
• Single current sinking or current sourcing output
• Rail-to-rail operation provides more usable signal for higher
accuracy
• Temperature-compensated magnetics help provide stable
operation over a wide temperature range of -40°C to 150°C
[-40°F to 302°F]
POTENTIAL APPLICATIONS
Industrial:
• Basic current sensing for motor load monitoring, detection
• Anti-tampering magnetic field sensor in smart remote utility
meters
• Pump control in heavy-duty equipment and household
appliances
• Simple linear or angular displacement sensing
• Handlebar/throttle position sensing in e-bikes and scooters
• Current sensing in appliances
• Speed adjustment trigger in tools and appliances
• Magnetic code reading in safes, security and building
access control systems
Medical: Position sensing in infusion pumps
Datasheet:
Operating supply voltage | 9 V |
Minimum operating temperature | - 40 C |
Maximum operating temperature | + 150 C |
Mounting Style | Through Hole |
Package/Case | TO-92-Flat-3 |
Supply Voltage - Maximum | 10.5 V |
Supply Voltage - Min | 4.5 V |
Unit weight | 120 mg |
