Non Dispersive Infrared Carbon Dioxide Sensor MSH-P/CO2/NC/5/V/P Range 0-20% Vol

Product Description:

Non-Dispersive Infrared Carbon Dioxide Sensor MSH-P/CO2/NC/5/V/P Range 0-20%vol For Combustible Gas Detector

Features:

Infrared carbon dioxide sensor MSH-CO2

In petrochemical, chemical and coal fields, tens of thousands of combustible gas detectors, including portable or fixed-mount models, are used to monitor safety in production. The performance and quality of the detector are the key of the safety monitoring system, and the sensor is the core of the detector. Therefore, the reliability, stability and maintenance cost of the sensor must be considered by the user in the selection of important issues, in order to achieve the purpose of safety monitoring. In recent years, with the continuous improvement of safety concepts and attention, the majority of industrial users are also constantly improving the requirements of gas detection products. In China, there are a lot of gas detection manufacturers with high technical ability emerge at the historic moment, and many high-quality brands have been recognized by the majority of users

UK Dynament Co., LTD. Non-dispersive infrared carbon dioxide Characteristics:

1, non-dispersive infrared gas sensor: diameter 20mm,16.6mm

2. Insert type (5 pins)

3, sensor power supply: 3-5V

4, simulate 0.4-2.0V voltage signal output

5, digital Tx,Rx output (RS232)

6, integrated circuit, built-in temperature compensation function

7, directly replace the catalytic combustion principle sensor

DYNAMENT in the UK applies the principle of non-dispersive infrared to realize the high-precision detection of combustible gas, carbon dioxide and other gases.

Features: Fast replacement of catalytic sensor without other peripheral compensation circuit, only need to output the Dynament infrared sensor 0.4-2V signal

Convert to 4-20mA

Explosion-proof or non-explosion-proof housing

Combustible gas detection range: 0-5%Vol, 0-LEL or 0-Vol methane or other specific flammable gas such as: methane, ethane, propane, butane, pentane, ethylene, ethylene oxide, methanol, ethanol, bromomethane, toluene, ethyl acetate, etc

Sensor power supply: 0-5V voltage output (3.3VDA recommended) Output: 0.4-2V

Applicable to industry, coal mining and other industries

Specifications:
