DS4-NH3 Smart Digital Ammonia Gas Sensor Solid Polymer Electrochemical

Large Image : DS4-NH3 Smart Digital Ammonia Gas Sensor Solid Polymer Electrochemical

Product Details:

Place of Origin:	Germany
Brand Name:	EC Sensor
Model Number:	DS4-NH3

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Package
Delivery Time:	3-5workingdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000PCS/Months

Contact Now

DS4-NH3 Smart Digital Ammonia Gas Sensor Solid Polymer Electrochemical

Description

Detection Principle:	Solid Polymer Electrochemical Gas Detection Technology	Operating Current:	0.65mA @ 5V DC
Power-on Stabilization Time:	< 2min (no Need To Warm Up The Machine, Just Power On And Test)	Error Range:	± 5% F.S
Perating Humidity Range:	15-95%RH. Non-condensing	Operating Pressure Range Atmospheric Pressure:	±10%
Repeatability:	< ± 2%	Operating Voltage:	3.3 To 12V DC, 5V DC Recommended
Highlight:	2min Stabilization Time Electrochemical Gas Sensor , DS4-NH3 Electrochemical Gas Sensor , Solid Polymer Electrochemical Gas Sensor

DS4-NH3 Smart Digital Ammonia Gas Sensor Solid Polymer Electrochemical

Features
1. Low power consumption, wide range power supply from 3.3 to
12V DC (5V recommended).
2. Wide operating temperature range from -40 ℃C to +55 ℃, without
temperature compensation.
3. Long-term zero point stability.
4. Fast response time and timely detection of gas concentration
changes.
5. Excellent linearity.
6. Anti-poisoning and long lifetime.
7. Solidification design of the electrolyte, avoiding the risk of liquid
leakage caused by high humidity environments or material aging.

Specifications

Principle	Solid Polymer Electrochemical Sensing Technology
Accuracy	± 5% F.S
Repeatability	< 2%
Linearity	Linear
Warm-Up Time	< 60 s

DS4-NH3 Smart Digital Ammonia Gas Sensor Solid Polymer Electrochemical 0
