Product Details:
|
| Part Number: | CLE-0231-400 | Resolution: | 0.1% O2 |
|---|---|---|---|
| Zero Signal: | -40 ~ 10 μA In Nitrogen | Maximum Overload: | 90% O2 |
| Output Signal: | -350 ± 50 μA In Air | Nominal Range: | 0 To 30% O2 |
| Highlight: | Rapid Response Gas Sensor,4OL Gas Sensor,CLE-0231-400 Gas Sensor |
||
4OL CLE-0231-400 Oxygen Gas Sensors 0-30% Vol New Style
Performance Characteristics
| Part Number | CLE-0231-400 |
| Nominal Range | 0 to 30% O2 |
| Maximum Overload | 90% O2 |
| Output Signal | -350 ± 50 μA in air |
| Zero Signal | -40 ~ 10 μA in Nitrogen |
| Resolution | 0.1% O2 |
| Response Time (T90) | ≤ 30 seconds |
| Linearity | Linear |
| Long Term Output Drift | < 2% signal/3 months |
Operation Conditions
| Temperature Range | -20℃ to 50℃ |
| Operating Humidity | 5 to 90%RH non-condensing |
| Pressure Range | 80 to 120 kPa |
| Bias Potential | -600 mV |
| Storage Life | 6 months in sealed container |
| Storage Temperature | 0℃ to 20 ℃ |
| Expected Operating Life | 2 years in air |
| Warranty | 18 months from date of despatch |
