Product Details:
|
| Nominal Range: | 0 - 100 Ppm | Maximum Overload: | 200 Ppm |
|---|---|---|---|
| Output Signal: | - 90 ± 60 NA/ppm | Resolution (Electronics Dependent): | < 1 Ppm |
| T90 Response Time: | < 60 S | Typical Baseline Range (pure Air, 20°C): | -2.0 Ppm To 1.0 Ppm |
| Highlight: | Selective Measurement Acetic Acid Gas Sensor,Compact Housing Acetic Acid Gas Sensor |
||
Acid/C-100 3-Electrode Electrochemical Acetic Acid Gas Sensor RCOOH Gas Sensor In Compact Housing Selective Measurement Of Organic Acids
Applications:
• Safety and Process Control
• Continuous Air Quality Monitoring
Electrical:
Rec. Load Resistor :10 - 33 Ω
Bias (V_Sens-V_Ref) :not allowed
Conformity to RoHS directive :RoHS Compliance
Environmental:
Relative Humidity Range :15 % to 90 % RH non-condensing
Temperature Range: -10 °C to 50 °C
Pressure Range :Atmospheric
Pressure Coefficient :N.D.
Humidity Effect: None
| Expected Operation Life | 2 years in air |
| Expected Long Term Output Drift in air | < 2 % signal loss per month |
| Filter Life | not applicable |
| Storage Life | 6 months in container |
| Rec. Storage Temperature | 5°C - 20°C |
