Product Details:
|
| Detection Range: | 0～20ppm | Max Range: | 150ppm |
|---|---|---|---|
| Sensitivity: | （1.2±0.3）µA/ppm | Resolution: | 0.1ppm |
| Response Time(T90): | ＜30S | Bias Voltage: | 10Ω(recommended) |
| Highlight: | Oxygen Nitrogen Dioxide Gas Sensor,Constant Potential Electrolysis Gas Sensor |
||
ME4-NO2 Nitrogen Dioxide Gas Sensor Is Constant Potential Electrolysis Type Oxidation-reduction Reaction With Nitrogen Dioxide And Oxygen Take Place Respectively On The Working Electrode
Profile :
ME4-NO2 nitrogen dioxide gas sensor is constant potential electrolysis type. Oxidation-reduction reaction with nitrogen dioxide and oxygen take place respectively on the working electrode and on the counter electrode. The process releases electric charge and generates current. The current is in direct proportion to the concentration of nitrogen dioxide. So the concentration of the target gas could be got by measuring the value of current. Features Low power consumption, high precision, high sensitivity, wide linear range, good anti-interference ability, excellent repeatability and stability. Main applications It is used for nitrogen dioxide detection in industrial occasions, mine and environmental protection field.
Features:
Low power consumption, high precision, high sensitivity, wide linear range, good anti-interference ability, excellent repeatability and stability.
Main applications:
It is used for nitrogen dioxide detection in industrial occasions, mine and environmental protection field.
| Output Linearity | Linear |
| Zero drift(-20℃～40℃) | 0.2ppm |
| Temperature range | -20℃～50℃ |
| Humidity range | 15﹪～90﹪RH |
| Pressure range | standard atmospheric pressure±10﹪ |
