Product Details:
Model Number: MQ-6
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 3-5work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

MQ-6 MOS Flammable Gas Sensor For Methane CH4 LPG Detection Industrial Flammable Gas Alarm And Portable Gas Detector

Description
Sensor Type: Semiconductor Standard Encapsulation: Bakelite, Metal Cap
Target Gas: LPG, CH4 Detection Range: 300~10000ppm(CH4,C3H8)
Loop Voltage: 5.0V±0.1V DC Load Resistance: Adjustable
Highlight:

Industrial Flammable Gas Sensor

,

Portable Gas Sensor

MQ-6 MOS Flammable Gas Sensor For Methane CH4 LPG Detection Industrial Flammable Gas Alarm And Portable Gas Detector



Profile:

Sensitive material of MQ-6 gas sensor is SnO2,which with lower conductivity in clean air. When the target flammable gas exist, the sensor’s conductivity gets higher along with the gas concentration rising. Users can convert the change of conductivity to correspond output signal of gas concentration through a simple circuit. MQ-6 gas sensor has high sensitivity to butane, propane, methane and can detect methane and propane at the same time. It also can detect kinds of flammable gases, especially LPG(Propane). It is a kind of low–cost sensor for many applications.



Features :

It has good sensitivity to flammable gas (Especially Propane) in wide range, and has advantages suchaslong lifespan, low cost and simple drive circuit &etc.



Main Applications:

It is widely used in domestic gas leakage alarm, industrial flammable gas alarm and portable gas detector



Concentration Slope ≤0.6(R3000ppm/R1000ppm C3H8)
Tem. Humidity 20℃±2℃;55%±5%RH
Standard test circuit Vc:5.0V±0.1V
Preheat time Not less than 48 hours
Lifespan 10 years
