Product Details:
|
| Detected Gas: | Carbon Monoxide | Interfering Gases: | Alcohol And Other Gases |
|---|---|---|---|
| Output Data: | UART Output | Operating Voltage: | 5V To 12V DC |
| Highlight: | Household Carbon Monoxide CO Module,Electrochemical Carbon Monoxide CO Module |
||
Product Description:
ZE15-CO Electrochemical Carbon Monoxide CO Module Is Used In Household Carbon Monoxide Alarms
Features:
ZE15-CO electrochemical carbon monoxide module is a universal and miniaturized module. The electrochemical principle is used to detect CO in the air, which has good selectivity and stability. Built-in temperature sensor for temperature compensation; Digital output and analog voltage output at the same time, easy to use. ZE15-CO is a versatile gas module designed and manufactured by combining mature electrochemical detection technology with sophisticated circuit design.
Product model ZE15-CO
Detection gas carbon monoxide
Interfering gases Alcohol and other gases
Output data UART output
Operating voltage 5V to 12V DC
Preheat time 30 seconds
Response time ≤30 seconds
Recovery time ≤30 seconds
Measuring range 0 ~ 500ppm
Resolution 0.1ppm
Operating temperature -10℃ ~ 55℃
Working humidity 15%RH-90%RH (non-condensing)
Storage temperature -10 ° C to 55 ° C
Service life 3-5 years (in the air)
Specifications:
| Preheat time | 30 seconds |
| Response time | ≤30 seconds |
| Measuring range | 0 ~ 500ppm |
| Resolution | 0.1ppm |
