YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments

YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments
YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments

Large Image :  YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments

Product Details:
Place of Origin: CHINA
Brand Name: YJJ
Model Number: G4-CH4
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: boxed
Delivery Time: 3 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2200

YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments

Description
Detectable Gas Type: Methane Accuracy: ± 2% L E L (≤ 50% F S) ± 4% L E L (> 50%
Output Type: Digital, Analog Operating Temperature: -40~70℃ Power
Supply Voltage: 3.3~5.0V
Highlight:

Measuring Instruments Infrared Methane Gas Sensor

,

Oxygen-free Infrared Methane Gas Sensor

,

Explosion-proof Infrared Methane Gas Sensor

Product Description:

G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments



Features:

G4 infrared gas sensor is an intelligent micro gas sensor designed based on the NDIR principle. It uses gas to measure the concentration of specific infrared spectrum absorption characteristics. It is designed in accordance with dual wavelength optical path, without oxygen dependence and catalytic poisoning of the sensor, with long life, high accuracy and stable performance. The sensor has analog and digital signal output interfaces, which can directly output the gas concentration value signal through linearization and temperature compensation, and is easier to use.

• High resolution, 0-10%VOL range resolution is 0.01%, 10%-100% VOL range resolution is 0.1%



• Range up to 0-100% VOL



• Linear, temperature compensated data output



• Digital and analog signal output



• Wide temperature range from -40℃ to 70℃



• Long-term stability, easy calibration



• No "poisoning" of catalytic sensors



• No oxygen dependence



• Intrinsic safety explosion-proof



• Dual wavelength optical path design



Specifications:

Gas type and range 100 % L E L methyl
Corresponding time T 90 < 20 S (free diffusion)
Inspection accuracy ± 2% L E L (≤ 50% F S) ± 4% L E L (> 50% F S)
Resolution 1 % L E L



YJJ G4-CH4 Infrared Methane Gas Sensor Is Explosion-proof And Oxygen-freeFor Measuring Instruments 0
