High Accuracy PSR 11-55-HL Oxygen Sensor Model Signal Output 10-13.5 mV Excellent Precision And Stability Accuracy Full Scale 2 1%

Large Image : High Accuracy PSR 11-55-HL Oxygen Sensor Model Signal Output 10-13.5 mV Excellent Precision And Stability Accuracy Full Scale 2 1%

Product Details:

Place of Origin:	USA
Brand Name:	Analytical Industries
Model Number:	PSR 11-55-HL

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Package
Delivery Time:	3-5workingdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000pcs/Month

Contact Now

High Accuracy PSR 11-55-HL Oxygen Sensor Model Signal Output 10-13.5 mV Excellent Precision And Stability Accuracy Full Scale 2 1%

Description

Measuring Range:

0-100% O2

Signal Output:

10-13.5 MV

Response Time 90%:

6 Seconds

Accuracy Full Scale (2):

+ 1%

Highlight:

High Accuracy Oxygen Sensor

10-13.5 mV Oxygen Sensor

PSR 11-55-HL Oxygen Sensor

PSR 11-55-HL Oxygen Sensor Model Output In Air Excellent Precision And Stability

Advanced galvanic type % oxygen sensors with excellent stability and accuracy under stringent applications.
All % oxygen sensors are subjected to the most extensive stability test, output in air, 30” of water column
pressure test and stability at 100% oxygen.

Accuracy FS Over Operating Temperature	+ 5%
Drift (% Signal Month)	< 1%
Humidity non-condensing	0-99% RH
Temperature Coefficient	Compensated
Operating Temperature	0-45°C
Operating Pressure Constant	5-30 PSIG
Flow Rate	1-10 LPM
Expected Life (1)	60 Months
Storage (4)	0 to 40°C
Warranty (5)	15 Months
Electrical Connections	Phono Plug

High Accuracy PSR 11-55-HL Oxygen Sensor Model Signal Output 10-13.5 mV Excellent Precision And Stability Accuracy Full Scale 2 1% 0
