PSR11-917-M Oxygen Gas Sensors Electrochemical Technology for Accurate 9-14 mV Signal Output and 1% Full Scale Accuracy

Large Image : PSR11-917-M Oxygen Gas Sensors Electrochemical Technology for Accurate 9-14 mV Signal Output and 1% Full Scale Accuracy

Product Details:

Place of Origin:	USA
Brand Name:	Analytical Industries Inc
Model Number:	PSR11-917-M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Package
Delivery Time:	3-5workingdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000pcs/Month

Contact Now

PSR11-917-M Oxygen Gas Sensors Electrochemical Technology for Accurate 9-14 mV Signal Output and 1% Full Scale Accuracy

Description

Measuring Range:

0-100% O2

Signal Output:

9-14 MV

Response Time 90%:

13 Seconds

Accuracy Full Scale:

+ 1%

Highlight:

Electrochemical Technology Oxygen Gas Sensors

PSR11-917-M Oxygen Gas Sensors

PSR11-917-M Oxygen Gas Sensors Electrochemical New

Advanced galvanic type % oxygen sensors with excellent stability and accuracy under stringent
applications. All % oxygen sensors are subjected to the most extensive stability test, output in air, 30” of water column pressure test and stability at 100% oxygen.

The widest range of oxygen sensors offered by Analytical Industries, Inc. are “Made in USA”

Datasheet:

Accuracy FS Over Operating Temperature	± 5%
Drift	< 1%
Linearity	± 1%
Humidity non-condensing	0-99% RH
Temperature Coefficient	Compensated
Operating Temperature	0-45°C
Operating Pressure Constant	5-30 PSIG
Flow Rate	.1-10 LPM
Expected Life	60 Months
Storage	0 to 40°C
Warranty	18 Months
Electrical Connections	3 Pin Molex
Recommended Storage	< 6 months

PSR11-917-M Oxygen Gas Sensors Electrochemical Technology for Accurate 9-14 mV Signal Output and 1% Full Scale Accuracy 0
