Product Details:
|
| Accuracy Error: | ±2%RH | Repeatability: | ±0.1%RH |
|---|---|---|---|
| Hysteresis: | ±1.0%RH | Non-linearity: | <0.1%RH |
| Highlight: | ZS13A Humidity Sensor Module,ZS13A Temperature Sensor Module,ZS13A Temperature Humidity Sensor Module |
||
ZS13A Temperature and Humidity Sensor Module
ZS13A is a brand new product, which is equipped with special ASIC sensor chip, high-performance semiconductor silicon-based capacitive humidity sensor and a standard on-chip temperature sensor, it uses standard I²C output signal format. ZS13 products have stable performance in high temperature and high humidity environment; At the same time, the product has great advantages in accuracy, response time and measurement range. Each sensor is strictly calibrated and tested before leaving the factory to ensure and meet the large-scale application of customers.
Specifications:
Relative humidity
| Parameter | Condition | Min | Typical | Max | Unit |
| Resolution | Typical | - | 0.024 | - | %RH |
| Accuracy error | Typical | - | ±2 | Refer toFigure 1 | %RH |
| Repeatability | - | - | ±0.1 | - | %RH |
| Hysteresis | - | - | ±1.0 | - | %RH |
| Non-linearity | - | - | <0.1 | - | %RH |
| Response time | τ63 % | - | <8 | - | s |
| Working Range | - | 0 | - | 100 | %RH |
| Prolonged Drift4 | Normal | - | < 1 | - | %RH/yr |
Technical parameters of temperature
| Parameter | Condition | Min | Typical | Max | Unit |
| Resolution | Typical | - | 0.01 | - | °C |
| Accuracy error5 | Typical | - | ±0.3 | - | °C |
| Max | See figure2 | - | |||
| Repeatability | - | - | ±0.1 | - | °C |
| Hysteresis | - | - | ±0.1 | - | °C |
| Response time6 | τ63% | 5 | - | 30 | s |
| Working Range | - | -40 | - | 85 | °C |
| Prolonged Drift | - | - | <0.04 | - | °C/yr |
