YJJ SS449A Hall Effect Sensor Is A 3.8V Digital lock Single-Pole For Low-Voltage Applications

Product Description:

SS449A Hall Effect Sensor Is A 3.8V Digital lock Single-Pole For Low-Voltage Applications

Features:

SS400 series and SS500 series of lock-in position sensor integrated circuits are single-pole digital Hall effect sensor integrated circuits with low, medium and high magnetic field strengths. Flat TO-92 style, SOT-89B package. The digital current sink output SS400 series sensor integrated circuit is a small general-purpose digital Hall effect sensor. It operates by the magnetic field provided by a permanent magnet or an electromagnet, and is used to respond to the alternating north and south magnetic poles or only to the south magnetic pole. Bipolar latch magnets and unipolar magnets are available for selection.

The bandgap adjustment function helps ensure stable operation within the power supply voltage range of 3.8Vdc to 30Vdc. These sensors can achieve a continuous current output of 20 mA and can cycle at a current of up to 50 mA. Its ability to operate at 3.8V voltage can be used in many potential low-voltage applications.

The digital open-circuit collector current sink output can be easily connected and used with various electronic circuits.

To provide reliable products and maintain consistent quality, the SS400 series has been tested at both 25°C [75°F] and 125°C [257°F]. All the catalogue products in this series can operate at a temperature of 150°C [302°F].

For the sake of design flexibility, the following pins and packaging options are provided:

Straight pins, 14.99mm [0.59 inches] in length, packed in bulk or in roll-up boxes

Straight pins, 18.7mm [0.735 inches] long, bulk packaging

Formed pins, 14.99mm [0.59 inches] in length, packed in bulk or in roll form boxes

Potential application

Industry

High-frequency flow sensing in HVAC, water meters, fuel meters and gas utility meters

Tamper-proof detection in water meters, electricity meters and gas meters

Liquid level detection

Motor speed sensing

Position sensing in the cylinder

Medicine

Rotational speed sensing in sports and rehabilitation equipment

Magnetic interruption in sports and rehabilitation equipment

Detection of missing/present in infusion pumps

The position sensing of the drawers in the medicine distribution cabinet

White products for sensing the tilt position in hospital beds

Detection of the positions of LIDS, doors and drawers

Fluid flow detection

Liquid level detection

Specifications:
