ES1-AG1-10 ES1-AG1-200 ES1-AG1-1000 Electrochemical VOC Gas Sensor

                        ES1-AG1-10 ES1-AG1-200 ES1-AG1-1000 Electrochemical VOC Gas Sensor

Basic Information:

• Detection Principle: Adopts EC Sense (Germany) solid-state polymer electrochemical detection technology. Based on electrochemical catalytic reaction, the sensor generates a micro-current signal proportional to the concentration of the target gas.
• Ordering Number: 01-ES1-AG1-10-01.
• Detected Gas: VOC (Volatile Organic Compounds).

Performance Parameters:

• Detection Range: 0 - 10ppm.
• Resolution: 0.01ppm.
• Sensitivity: 55±15nA/ppm (calibrated with C₄H₈).
• Working Principle: Amperometric, 3-electrode design.
• Temperature Range: -40°C to 55°C.
• Humidity Range: 10 - 95% RH (non-condensing).
• Pressure Range: 800 to 1200 hPa.
• Overload Capacity: 100ppm.
• Repeatability: 1%.
• Warm-up Time: Typically <60 seconds.
• Response Time: T50<10 seconds, T90<30 seconds.
• Weight: <0.7g.
• Dimensions: 11.5x11.5x5.5mm (pinless).

Additional Features:

• Long Service Life: >3 years.
• Anti-poisoning Capability.
• Zero Power Consumption.
• Linear Output.
• No Zero Drift.
• High Signal-to-Noise Ratio.
• Complies with RoHS standards.

Application Fields:

Applied to devices requiring VOC gas detection, such as air purifiers, to monitor VOC concentration in the environment and provide data support for air quality assessment and health protection.
