YJJ GS+5CO-M Electrochemical Carbon Monoxide CO Gas Sensor 0-4000ppm Measurement Range for Smoke Gas Monitoring

Product Description:

GS+5CO-M Electrochemical Carbon Monoxide (CO) Gas Sensor Is Used For Smoke Gas Monitoring

Features:

GS+5CO is a four-electrode carbon monoxide sensor that takes hydrogen compensation into account. It is optimally designed and complies with the strict requirements of EN50379 Part 1. It is applied in the field of strict flue gas monitoring.

Sensitivity / nA/ppm: 75 ± 25

Baseline range (clean air) / ppm: ± 5

Filtering capacity / ppm-hour: > 100,000 acidic gases

T90 response time / second: < 40

Measurement range / ppm: 0 - 4000

Overload / ppm: 10000

Is H2 compensation available? : Yes

Repeatability / CO equivalence: < ±2%

Recommended load resistance / ohm: 10

Resolution / ppm typical value: < 1

Continuous operating temperature: -30°C to +50°C

Pressure range: 800 to 1200 mbar

Working humidity: 15% to 90% RH

Long-term output drift / per year: < 5%

Recommended storage temperature /: 0°C to 20°C

Working life / in air: > 24

Guarantee: 12
