PSR 11-75-KE8 Oxygen Sensor Model Excellent Stability And Accuracy

Large Image : PSR 11-75-KE8 Oxygen Sensor Model Excellent Stability And Accuracy

Product Details:

Place of Origin:	USA
Brand Name:	All Analytical
Model Number:	PSR 11-75-KE8

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Package
Delivery Time:	3-5workingdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	2000pcs/Month

Contact Now

PSR 11-75-KE8 Oxygen Sensor Model Excellent Stability And Accuracy

Description

Measuring Range:

0-100% O2

Signal Output:

10-14 MV

Response Time 90%:

13 Seconds

Accuracy Full Scale:

+ 1%

Highlight:

PSR oxygen sensor high accuracy

gas sensor excellent stability

oxygen sensor model KE8

PSR 11-75-KE8 Oxygen Sensor Model Excellent Stability And Accuracy

Advanced galvanic type % oxygen sensors with excellent stability and accuracy under stringent applications. All % oxygen sensors are subjected to the most extensive stability test, output in air, 30” of water column pressure test and stability at 100% oxygen.
The widest range of oxygen sensors offered by Analytical Industries, Inc. are “Made in USA”

Accuracy FS Over Operating Temperature	+ 5%
Drift (% Signal Month)	< 1%
Humidity non-condensing	0-99% RH
Temperature Coefficient	Compensated
Operating Temperature	0-45°C
Operating Pressure Constant	5-30 PSIG
Flow Rate	1-10 LPM
Expected Life	60 Months
Storage	0 to 40°C
Warranty	24 Months
Electrical Connections Winchester	3 Pin Connector

PSR 11-75-KE8 Oxygen Sensor Model Excellent Stability And Accuracy 0
