MSH-P/CO2/NC/5/V/P/F Dual Range Carbon Dioxide Sensor Gas Sensors Premier Plantinum Infrared

Large Image : MSH-P/CO2/NC/5/V/P/F Dual Range Carbon Dioxide Sensor Gas Sensors Premier Plantinum Infrared

Product Details:

Place of Origin:	UK
Brand Name:	Dynament
Model Number:	MSH-P/CO2/NC/5/V/P/F

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Box
Delivery Time:	3-5workingdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000PCS/Months

Contact Now

MSH-P/CO2/NC/5/V/P/F Dual Range Carbon Dioxide Sensor Gas Sensors Premier Plantinum Infrared

Description

Operating Voltage Range:

3.0 – 5.0 V D.c.

Operating Current:

75 – 85mA

Output Voltage Ranges:

0.1V To 2.7V D.c.

Volume Measuring Ranges:

0 - 5%, 0-4%, 0-3%, 0-2%, 0-1% Volume CO2

Highlight:

dual range carbon dioxide sensor

infrared CO2 gas sensor

platinum gas sensor with warranty

MSH-P/CO2/NC/5/V/P/F Dual Range Carbon Dioxide Sensor Gas Sensors Premier Plantinum Infrared

FEATURES
* High resolution infrared sensor measures carbon dioxide from 0 to 5% volume with a resolution
of 0.01 % volume.
* Parts per million range available from 0-500ppm to 0-10,000ppm with a resolution of 10ppm.
* Offers reduced response times when compared with earlier versions.
* Contains all the necessary optics, electronics and firmware to provide a linearised,
temperature-compensated output.
* Choice of output format – digital output (floating point and binary), direct pellistor replacement
or industry standard 0.4 to 2 volts.
* Manual calibration option can be performed without digital commands.
* User configurable using USB powered Premier Configuration Unit.
* Analogue output is scaleable in % volume or % FSD.
* Internal Flash memory allowing sensor firmware updates via configuration equipment.
* Enhanced EMC protection

Specification:

Measuring ranges	0-500ppm up to 0-10000ppm CO2
Resolution	0.01% for volume readings. 10ppm for parts per million readings.
Output voltage resolution	42.7 µV
Accuracy	± 2%
Pressure within	± 5%

MSH-P/CO2/NC/5/V/P/F Dual Range Carbon Dioxide Sensor Gas Sensors Premier Plantinum Infrared 0
