SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis

SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis
SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis

Large Image :  SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis

Product Details:
Place of Origin: UK
Brand Name: PSR
Model Number: SO2-B4
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiable
Packaging Details: Standard packaging
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000PCS
Contact Now

SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis

Description
Measuring Range: 0 - 100 Ppm Sensitivity: 275 - 500 NA/ppm
Response Time (t90): < 60 S Zero Current: - 100 - + 100 NA
Resolution: 5 Ppb Maximum Overload: 200 Ppm
Highlight:

SO2-B4 sulfur dioxide gas sensor

,

electrochemical gas sensor for air quality

,

flue gas analysis SO2 sensor



                   SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis





Technical Features:

  • High - precision Detection: Using proven fuel cell technology, with strong signal levels and low zero current, the resolution can reach < 10 ppb, which can meet the requirements of high - precision detection in air quality networks.
  • Good Linearity: The linearity error is 0 - 2 ppb at 100 ppm SO2, and it is linear in the range of 0 - 10 ppm SO2, which can ensure the accuracy of measurement results.
  • Reliable Performance: The sensor provides an electrolyte leak - free guarantee and reliable long - term detection performance. The leak - proof housing is molded with a color - coded top for easy identification.

Application Scenarios:

It is suitable for fixed - installation sensing heads, portable safety instruments, urban/indoor air monitoring and stack gas analyzers, etc., and can provide reliable data support for air quality monitoring and industrial emission detection.



Measuring Range 100 ppm
Sensitivity 275 - 475 nA/ppm (at 2 ppm SO2)
Response Time (t90) < 30 s (from zero to 2 ppm SO2)
Zero Current in Zero Air at 20℃ -
Noise (±2 standard deviations, ppb equivalent) 5
Resolution < 1 ppm
Linearity 0 - 2 ppb error at 100 ppm SO2, linear at 0 and 10 ppm SO2
Over - gas Limit 200 ppm
Zero Drift (ppb equivalent change/year in lab air) < ±20
Sensitivity Drift (% change/year in lab air, monthly test) < ±15
Operating Life > 36 months (until 50% of the original signal)
Sensitivity at - 20℃ 70 - 82% (output at - 20℃ / output at 20℃ @ 2 ppm SO2)
Sensitivity at 50℃ 95 - 110% (output at 50℃ / output at 20℃ @ 2 ppm SO2)
Zero at - 20℃ (nA change from 20℃) 0 - 10
Zero at 50℃ (nA change from 20℃) 10 - 30
Filter Capacity 450 ppm·hrs
H2S Sensitivity (% measured gas @ 5 ppm H2S) < 2
NO2 Sensitivity (% measured gas @ 5 ppm NO2) < - 160
Cl2 Sensitivity (% measured gas @ 5 ppm Cl2) < - 40
NO Sensitivity (% measured gas @ 5 ppm NO) < - 2
CO Sensitivity (% measured gas @ 5 ppm CO) < 2
H2 Sensitivity (% measured gas @ 100 ppm H2) < 0.5
C2H4 Sensitivity (% measured gas @ 100 ppm C2H4) < 1
NH3 Sensitivity (% measured gas @ 20 ppm NH3) < 0.1
CO2 Sensitivity (% measured gas @ 5% CO2) < 0.1
Temperature Range - 30 to 50℃
Pressure Range 80 - 120 kPa
Humidity Range 15 - 90% RH (continuous)
Storage Period 6 months (@3 - 20℃, stored in sealed pot)
Load Resistor 33 - 100 Ω
Weight < 13 g



 SO2-B4 Electrochemical Sulfur Dioxide Gas Sensor For Air Quality Monitoring Flue Gas Analysis 0
