CO-AX Carbon Monoxide Gas Sensor Low Cross Sensitivity To Hydrogen

Large Image : CO-AX Carbon Monoxide Gas Sensor Low Cross Sensitivity To Hydrogen

Product Details:

Place of Origin:	UK
Brand Name:	Alphasense
Model Number:	CO-AX

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Box
Delivery Time:	3-5Workingdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000PCS/Month

Contact Now

CO-AX Carbon Monoxide Gas Sensor Low Cross Sensitivity To Hydrogen

Description

Sensitivity:

55 Fo 100

Response Time:

<30

Zero Current:

<±3

Resolution:

<0.5

Highlight:

CO-AX carbon monoxide gas sensor

low cross sensitivity gas sensor

hydrogen resistant CO gas sensor

CO-AX Carbon Monoxide Gas Sensor Low Cross Sensitivity To Hydrogen

Specification:

Sensitivity	55–100 nA/ppm (400 ppm CO)
T90 Response	<30 s (0 → 400 ppm)
Baseline	<±3 ppm equivalent
Resolution	<0.5 ppm (RMS noise)
Linearity	<±40 ppm (0–2000 ppm; 0–800 ppm optimal)
Load Resistor	10–47 Ω (10 Ω recommended)

Environmental Conditions & Lifespan

Temperature	−30°C to +50°C
Humidity	15%–90% RH (non-condensing)
Pressure	80–120 kPa
Lifespan	>24 months (in air; 2-year warranty)
Long-term Drift	Zero point <0.2 ppm/year; Sensitivity <6%/year
Storage	0–20°C, sealed, up to 6 months

CO-AX Carbon Monoxide Gas Sensor Low Cross Sensitivity To Hydrogen 0
