YJJ 4H2-10000 CLE-0614-400 Electrochemical Hydrogen H2 Sensor 0-10000 ppm

Product Description:

YJJ 4H2-10000 CLE-0614-400 Electrochemical Hydrogen H2 Sensor 0-10000 ppm

Features:

Official order number (CLE code) for the 4H2-10000 hydrogen sensor is: CLE-0614-400.
I. Model and Order Number Comparison (4H2 Series)
4H2-1000 (0 - 1000 ppm): CLE-0613-400
4H2-10000 (0 - 10000 ppm): CLE-0614-400
4H2-40000 (0 - 40000 ppm): CLE-0644-400
II. Key Parameters of 4H2-10000 (CLE-0614-400)
Detected Gas: Hydrogen (H2)
Range: 0 - 10000 ppm
Maximum Overload: 20000 ppm
Sensitivity: 0.03 ± 0.01 μA/ppm
Response Time (T90): ≤ 70 seconds
Operating Temperature: -20°C - +50°C
Service Life: 2 years in air
Size: Φ32 × 14.5 mm (4 Series Standard)
III. Purchase Notes
4H2-10000 is a general model. CLE-0614-400 is the internal order / production code of Hon
When placing an order, both models can be used. It is recommended to provide both to avoid wrong orders.
The low concentration (1000 ppm) of the same series is CLE-0613-400, and the high concentration (40000 ppm) is CLE-0644-400.
