CL2-A1 Three-electrode Electrochemical Chlorine (Cl2) Gas Sensor for Water Treatment Industry Monitoring

Large Image : CL2-A1 Three-electrode Electrochemical Chlorine (Cl2) Gas Sensor for Water Treatment Industry Monitoring

Product Details:

Place of Origin:	UK
Model Number:	CL2-A1

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiable
Packaging Details:	Paper box
Delivery Time:	5-8 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5000PCS

Contact Now

CL2-A1 Three-electrode Electrochemical Chlorine (Cl2) Gas Sensor for Water Treatment Industry Monitoring

Description

Working Principle:	3-electrode Electrochemical Principle	Standard Measuring Range:	0-20 Ppm
Maximum Overload Concentration:	35 Ppm	Resolution:	20 Ppb
T90 Response Time:	< 60 S	RMS Noise:	< 0.02 Ppm Equivalent
Highlight:	three-electrode chlorine gas sensor , electrochemical Cl2 sensor for water treatment , industrial chlorine monitoring gas sensor

CL2-A1 Three-electrode Electrochemical Chlorine (Cl2) Gas Sensor for Water Treatment Industry Monitoring

Product Model	CL2-A1
Detected Gas	Chlorine (Cl2)
Working Principle	3-electrode Electrochemical Principle
Standard Measuring Range	0–20 ppm
Maximum Overload Concentration	35 ppm
Sensitivity (@10ppm Cl2)	-350 ~ -750 nA/ppm
Resolution	20 ppb (ultra-high resolution)
T90 Response Time	< 60 s
RMS Noise	< 0.02 ppm equivalent
Baseline Offset (@20℃)	< 0.02 ppm equivalent
Linearity	Highly Linear (≤ 2% deviation)
Bias Voltage	0 mV (Zero bias)
Operating Temperature Range	-20℃ ~ 50℃
Operating Humidity Range	15%–90% RH (non-condensing)
Operating Pressure Range	90–110 kPa
Long-term Stability	< 2% signal value / month
Storage Temperature Range	0℃ ~ 20℃
Service Life	24 months (in ambient air)
Storage Life	6 months (sealed original package)
Weight	Approx. 5 g

CL2-A1 Three-electrode Electrochemical Chlorine (Cl2) Gas Sensor for Water Treatment Industry Monitoring 0
