MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor

I'm Online Chat Now

MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor

MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor
MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor

Large Image :  MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor

Product Details:
Place of Origin: China
Brand Name: Winsen
Model Number: MH-Z16
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Standard Box
Delivery Time: 3-5Workingdays
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/Month

MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor

Description
Product Model: MH-Z16 Detection Gas: Carbon Dioxide
Supply Voltage: DC(5.0±0.1)V Average Current: <85mA (@5V Power Supply)
Peak Current: 150mA (@5V Power Supply) Interface Level: 3.3V (compatible With 5V)
Measuring Range: 0~50000ppm (extendable To 150000ppm)
Highlight:

MH-Z16 CO2 Sensor

,

Digital CO2 Sensor

,

Electrochemical Carbon Monoxide Sensor

MH-Z16 CO2 Carbon Monoxide Sensors Digital Qaveform Output



The MH-Z16 carbon dioxide gas sensor (hereinafter referred to as the sensor) is a general-purpose, small sensor, which uses the principle of non-dispersive infrared (NDIR) to detect CO2 in the air. It has good selectivity, no oxygen dependence, and long life. . Built-in temperature compensation; with digital output and waveform output at the same time, easy to use. The infrared sensor is a high-performance sensor made by closely combining mature infrared absorption gas detection technology with precise optical path design and sophisticated circuit design.



Specifications Sheet:

Warm-up time 10S
Response time T90 < 30s
Working temperature -10℃~50℃
Working humidity 0~95%RH (non-condensing)
Storage temperature -20℃~60℃
Weight <21g
Lifetime >10 years



MH-Z16 CO2 Sensor Digital Qaveform Output Electrochemical Carbon Monoxide Sensor 0
