SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly

SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly
SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly

Large Image :  SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly

Product Details:
Place of Origin: Switzerland
Brand Name: Sensirion
Model Number: SCD40
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Standard Box
Delivery Time: 3-5Workingdays
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000pcs/Month

SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly

Description
Product Category: Air Quality Sensors Type: Gas Sensor
Sensor Type: Carbon Dioxide (CO2) Operating Supply Voltage: 2.4 V To 5.5 V
Highlight:

SCD40

,

CO2 Air Quality Sensor

,

Photoacoustic CO2 Sensor

SCD40 Air Quality CO2 Sensor Carbon Dioxide Photoacoustic



The SCD4x is Sensirion’s next generation miniature CO2 sensor. This sensor builds on the photoacoustic sensing principle and Sensirion’s patented PAsens® and CMOSens® technology to offer high accuracy at an unmatched price and smallest form factor. SMD assembly allows cost- and space-effective integration of the sensor combined with maximal freedom of design. On-chip signal compensation is realized with the build-in SHT4x humidity and temperature sensor.

Features
▪ Photoacoustic sensor technology PASens®
▪ Smallest form factor: 10.1 x 10.1 x 6.5 mm3
▪ Reflow solderable for cost effective assembly
▪ Large output range: 0 ppm – 40’000 ppm
▪ Large supply voltage range: 2.4 – 5.5 V
▪ High accuracy: ±(40 ppm + 5 %)
▪ Digital I2C interface
▪ Integrated temperature and humidity sensor
▪ Low power operation down to < 0.4 mA avg.
@ 5 V, 1 meas. / 5 minutes



Datasheet:

Moisture Sensitivity Yes
Installation style SMD/SMT
Product Type Air Quality Sensors
Supply Voltage - Maximum 5.5 V
Supply Voltage - Min 2.4 V



SCD40 Photoacoustic CO2 Air Quality Sensor Carbon Dioxide SMD Assembly 0
