GS-ABC-3535LQC Red UV Photodiode Sensor SMD 3535 For Water Quality Detection

Product Description:

GS-ABC-3535LQC Red UV Sensor Is Used For UV Water Quality Detection

Features:

General Features: l UVA+UVB+UVC photodiode l Photovoltaic mode operation l SMD 3535 ceramic package with quartz window l Good visible blindness l High responsivity and low dark current Applications: air purification, water quality measurement

Parameters Symbol Value Unit Maximum ratings

Operation temperature range Topt -25-85 oC

Storage temperature range Tsto -40-85 oC

Soldering temperature (3 s) Tsol 260 oC

Reverse voltage Vr-max -10 V

General characteristics (25 oC) Chip size A 1 mm2 Dark current (Vr = -1 V) Id

<1 nA Temperature coefficient (@265 nm) Tc 0.05 %/ oC Capacitance (at 0 V and 1 MHz) Cp 18 p>

Specifications:
