Product Details:
|
| RH Range: | 0 % To 100 % | RH Accuracy: | +/- 3.5% |
|---|---|---|---|
| Installation Style: | Through Hole | Output Type: | Analog |
| Working Power Supply Current: | 200 UA | ||
| Highlight: | Board Installation Humidity Sensor IC,0% to 100% Humidity Sensor IC,200 uA Humidity Sensor IC |
||
Humidity Sensor HIH-462-C Description:
The HIH-4602-a/c series Relative humidity (rh) sensor has a to-5 housing with a waterproof sintered stainless steel filter that senses relative humidity and temperature. The rh sensor is built in
Laser modified thermosetting polymer capacitive induction element for signal processing unit. The HIH-462-A /c is a combination of temperature sensor and rh sensor ideal for testing dew point or it
It's absolutely moist. Hih-462-a /c contains a thermistor, and HIH-462-A /c contains a precision rtd. Each sensor corresponds to provide factory calibration data for each transmission
The sensor achieves ±3.5%rh accuracy.
Humidity Sensor HIH-462-C Features:
The voltage output corresponding to the relative humidity (%rh) is close to linear
Laser correction achieves interchangeability
High precision, fast response
Chemical resistance
Stable, low drift performance
Built-in electrostatic protection
Suitable for dew point and absolute moisture measurement
to-5 package
Humidity Sensor HIH-462-C Typical applications:
Refrigeration equipment
Heating Ventilation and Air Conditioning (hvac)
Medical equipment
Drying equipment
Measuring equipment
Battery powered system
Original Equipment Manufacturing Plant (oem) assemblies
| Supply voltage - Min | 4 V |
| Power supply voltage - Max | 5.8V |
| Minimum operating temperature | -40 C |
| Maximum operating temperature | + 85 C |
