Product Details:
|
| Flow/Pressure Range: | 0 SLPM To 20.0 SLPM | Output Voltage @ Trim Point: | 5.0 Vdc @ 20 SLPM |
|---|---|---|---|
| Port Style: | 1/4 In - 18 NPT | Null Shift Over Temperature: | ±0.050 Vdc Typ., ±0.20 Vdc Max. |
| Output Shift Over Temperature: | ±7 % Reading | Maximum Change In Flow Rate: | 5.0 SLPM/s |
| Highlight: | AWM5104VN Air Flow Sensor,Accurate Air Flow Sensor |
||
AWM5104VN Air Flow Sensor
Honeywell Air flow Sensors -AWM5104VN Description
AWM5000 Series Microbridge Mass Air flow Sensors feature a Venturi type flow housing. They measure flow as high as 20 standard liters per minute (SLPM) while inducing a maximum pressure drop of 2.25" H2O. The microbridge chip is in direct contact with the flow stream, greatly reducing error possibilities due to orifice or bypass channel clogging.
Honeywell Air flow Sensors -AWM5104VN Features
● Linear voltage output
● Venturi design
● Remote mounting capability
● Active laser trimming improves interchangeability
● Separate gas calibration types:
-Ar (argon)
-N2 (nitrogen) or
-CO2 (carbon dioxide)
Honeywell Air flow Sensors -AWM5104VN Potential Applications
● Damper control for heating, ventilation, and air conditioning systems
● Gas analyzers
● Low vacuum control
● Process control
● Medical respirators and ventilators
● Oxygen concentrators
● Leak detection equipment
● Vent hoods
● Anesthesia control
● Gas metering
● Gas chromatography
Honeywell Air flow Sensors -AWM5104VN Product Specifications
| Response Time | 60 ms max. |
| Supply Voltage | 8.0 Vdc min., 10.0 Vdc typ., 15.0 Vdc max. |
| Maximum Common Mode Pressure | 50.0 psi |
| Power Consumption | 100 mW max. |
| Operating Temperature Range | -20 °C to 70 °C [-4 °F to 158 °F] |
| Storage Temperature Range | -20 °C to 70 °C [-4 °F to 158 °F] |
| Media Compatibility | Dry gas only |
| Weight | 60 g |
| Availability | Global |
| UNSPSC Code | 411121 |
