AD590JH 2 Terminal Current Output IC Temperature Transducer for Precision Temperature Measurement & Control

Large Image : AD590JH 2 Terminal Current Output IC Temperature Transducer for Precision Temperature Measurement & Control

Product Details:

Place of Origin:	USA
Model Number:	AD590JH

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Paper box
Delivery Time:	3-5work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5000pcs

Contact Now

AD590JH 2 Terminal Current Output IC Temperature Transducer for Precision Temperature Measurement & Control

Description

Type:	2‑Terminal IC Temperature Transducer	Temperature Range:	−55°C To +150°C
Accuracy:	±5°C	Supply Voltage:	4 V To 30 V
Supply Current:	~1.5 MW @ 5 V, 25°C	Output Impedance:	> 10 MΩ
Highlight:	AD590JH temperature transducer IC , 2 terminal current output sensor , precision temperature measurement transducer

AD590JH 2 Terminal Current Output IC Temperature Transducer for Precision Temperature Measurement & Control

Key Features:

2 terminal design (voltage in, current out) simple interface
Wide supply range (4~30 V) flexible powering
High output impedance excellent long wire noise immunity
Laser trimmed calibration for high accuracy
Probe compatible ceramic package easy integration
Case isolation prevents ground loops

Typical Applications:

Precision temperature measurement & control
Remote temperature sensing (long cables)
Temperature compensation for circuits
Flow/level/anemometry systems
Industrial & medical temperature monitoring

Type	2 Terminal IC Temperature Transducer
Output	1 μA/K (current proportional to absolute temperature)
Temperature Range	−55°C to +150°C
Accuracy	±5°C (at 25°C)
Linearity	±0.3°C over full range (typical)
Supply Voltage	4 V to 30 V
Supply Current	~1.5 mW @ 5 V, 25°C
Output Impedance	> 10 MΩ
Package	3 Lead TO 52 (Metal Can)
Case Isolation	Sensor isolated from case

AD590JH 2 Terminal Current Output IC Temperature Transducer for Precision Temperature Measurement & Control 0
