YJJ FS5001L-2000-EV-A Small Flow Gas Mass Flow Sensor with 0.5% Repeatability and 500 Flow Range

Product Description:

FS5001L-2000-EV-A Small Flow Gas Mass Flow Sensor

Features:

FS5001 small flow gas mass flow sensor is specially designed for the measurement and process control of various small flow gases. This series of sensors are manufactured using the company's own microelectromechanical system (MEMS) flow sensing chip, suitable for all kinds of clean and dry gases. * packaging technology enables it to measure different ranges of flow under the same pipe diameter, low cost, easy installation, no need for temperature and pressure compensation, can replace the volumetric or differential pressure of the traditional flow sensor and equipped with a variety of signal output, through the communication interface can achieve flexible configuration of the sensor and parameter query.

Product features:

The sensor has high sensitivity and minimal starting flow rate

The sensor chip adopts thermal mass flow measurement without temperature and pressure compensation, which ensures the high precision measurement of the sensor

Multi-sensor integration is realized on a single chip, making its range ratio reach 100:1 or even higher

Wall-mounted installation, no straight pipe section, easy to install and use

The output mode is flexible, it can upload data actively through the communication interface (RS232) or query the output data by the host computer (RS232 / I2C), and also output linear analog voltage through the analog interface

High zero stability

Full range high stability, high accuracy and excellent repeatability

Low power consumption, low pressure loss

Fast response speed

Specifications:
