YJJ FS8001 Series Microcomputer-Based Electrical Mass Flow Sensor Is Used In Industrial Equipment

Product Description:

YJJ FS8001 Series Microcomputer-Based Electrical Mass Flow Sensor Is Used In Industrial Equipment

Features:

FS8001 series microcomputer electrical mass flow sensor is specially designed for various industrial process control. The product features a threaded interface, making it easy to install and applicable to a variety of industrial equipment such as wafer bonding machines.

The FS8001 series gas mass flow sensors are specially designed for industrial process control. They feature a threaded interface design and are suitable for industrial equipment such as crystal bonding machines. They support the measurement of gas media such as air. The key features of these sensors include:

Measurement range: 0 - 500 SCCM (standard cubic centimeters per minute)

Accuracy: ±(2.0 + 0.5FS)

Response time: ≤ 10ms

Operating temperature: 0 - 55℃

Output mode: Analog voltage (0.5 - 4.5VDC) or optional I2C digital signal

Interface type: M5 screw hole or JST electrical interface

This sensor features low power consumption and strong anti-interference capability, and can meet the requirements of high precision and response speed in scenarios such as semiconductor manufacturing and gas pipeline monitoring.

Flow range
‌Standard flow range‌: 0 - 500 sccm (under standard conditions)
Expand the flow range: Up to 6 SLPM (please confirm with the specific model)
Accuracy and Reproducibility
‌Accuracy‌: ±(2.0 + 0.5 × FS)%
Repeatability: ±1.0%
Output Characteristics
‌Output Mode‌: Linear analog voltage (0.5 - 4.5 VDC), optional I²C digital signal output
Response time: 10 ms
Working conditions
‌Working voltage‌: 8 - 24 VDC
Work pressure: 0.3 MPa
Working temperature: 0 to +55℃
Storage temperature: -20 to +65℃
Other features
‌Interface type‌: Threaded interface (M5 screw hole)
Humidity requirements: < 95% RH (no freezing, no condensation)

Specifications:
