281637 282049 282051 Flow sensor For Medical ventilators

Large Image : 281637 282049 282051 Flow sensor For Medical ventilators

Product Details:

Place of Origin:	USA
Model Number:	281637 282049 282051

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiable
Packaging Details:	Standard packaging
Delivery Time:	5-8 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5000PCS

Contact Now

281637 282049 282051 Flow sensor For Medical ventilators

Description

Flow Range:

0 To 180 L/min (short Term 260 L/min)

Dead Space:

< 11 Ml (functional)

Resistance:

< 0.027 CmH2O/(l/min) Over The Complete Flow Range (-180 L/min To 180 L/min)

Temperature:

Operating: -20°C To 50°C (-4°F To 122°F)

Highlight:

medical ventilator flow sensor

air flow sensor for ventilators

medical air flow sensor with warranty

281637 282049 282051 Flow sensor For Medical ventilators

Product Overview:

The 281637 is a compact, industrial-grade gas sensor designed for reliable detection of specific target gases (confirm target gas with manufacturer, e.g., carbon monoxide, methane, volatile organic compounds, or oxygen). It adopts semiconductor (metal oxide) or electrochemical sensing technology (depending on target gas) to deliver fast response, low power consumption, and stable long-term performance. Typical applications include industrial safety monitoring (e.g., factory leak detection), indoor air quality (IAQ) management, smart home safety systems, and portable gas detectors.

No.	Component/Parameter Category	Description	Specification/Details	Material	Remarks
1	Connector	Ventilator side	OD15	PSU	-
2	Tubing	-	-	PVC	-
3	Connectors for Tubing	Differential pressure measurement	-	PSU	-
4	Direction Index	-	-	-	-
5	Individual Serial Number	-	-	-	-
6	Connector	Patient side	OD22/ID15	PSU	-
7	Flap	-	-	PET	-
-	Technical Performance	Flow range	0 to 180 l/min (short term: 260 l/min)	-	-
-	Technical Performance	Dead space	< 11 ml (functional)	-	-
-	Technical Performance	Resistance	< 0.027 cmH₂O/(l/min) over the complete flow range (-180 l/min to 180 l/min)	-	-
-	Technical Performance	Weight	- Approx. 14 g (without tubes) - 68 g (with 188 cm tubes) - 89 g (with 260 cm tubes) - 110 g (with 330 cm tubes)	-	-
-	Material Compliance	Material standards	1. Complies with ISO 10993-1:2009 (biocompatibility) 2. Complies with Directive 2011/65/EU (RoHS) 3. No natural rubber latex, DEHP, or BPA	-	Ensures safety for medical use
-	Accuracy (Calibrated Flow Sensor)	Volume-related parameters (HAMILTON ventilators)	- HAMILTON-C1/T1/MR1/C2/C3/C6: ± 10% or ± 10 ml (whichever is greater) - HAMILTON-G5/S1: ± 15% or ± 20 ml (whichever is greater)

281637 282049 282051 Flow sensor For Medical ventilators 0
