YJJ MF5006-N-E-0.5-50-06-D-N 0.5-50SLPM Digital Gas Mass Flowmeter RS485 Modbus Thermal Flow Sensor

Product Description:

YJJ MF5006-N-E-0.5-50-06-D-N 0.5-50SLPM Digital Gas Mass Flowmeter RS485 Modbus Thermal Flow Sensor

Features:

I. Disassembly of Model MF5006-N-E-0.5-50-06-N-D-N-N
MF5006: MF5000 series, DN6 specification flowmeter
N: Standard version
E: With LCD display + physical buttons
0.5-50: Measurement range 0.5-50 SLPM (standard liters per minute)
06: Pipe interface NPT1/4-INCH external thread
D: Output: 4-20mA analog + RS485-Modbus communication
N: No special customization options
II. Complete technical parameters Table
Parameter Item Specification Details
Sensing Principle MEMS thermal micro-electromechanical sensing
Measurement Medium Nitrogen, air, oxygen, argon, etc. dry and non-corrosive gases
Measurement Accuracy ±(1.5% FS + 0.5% reading)
Response Time ≤ 125ms
Power Supply Voltage DC12-24V, maximum working current 20mA
Signal Output 4-20mA, RS485 Modbus-RTU, pulse output
Mechanical Interface NPT1/4 external thread
Maximum Pressure 1.5MPa
Environmental Temperature -20℃~+60℃
Medium Temperature -10℃~+55℃
Shell Material Aluminum alloy, flow channel stainless steel
Protection Grade IP40

Specifications:
