AMS3002H00 Thermal Gas Mass Flow Meter or Mass Flow Measurement Of clean Dry Gases

Large Image : AMS3002H00 Thermal Gas Mass Flow Meter or Mass Flow Measurement Of clean Dry Gases

Product Details:

Place of Origin:	China
Brand Name:	Asong
Model Number:	AMS3002H00

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Package
Delivery Time:	1-2Workingdays
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	3000PCS/Month

Contact Now

AMS3002H00 Thermal Gas Mass Flow Meter or Mass Flow Measurement Of clean Dry Gases

Description

Measuring Range:

20–2000 L/min

Accuracy:

±3% F.S. (in The 200–2000 L/min Range)

Repeatability:

±1% F.S.

Response Time:

1 S

Highlight:

thermal gas mass flow meter

clean dry gas flow measurement

medical air flow sensor

AMS3002H00 Thermal Gas Mass Flow Meter or Mass Flow Measurement Of clean Dry Gases

* Integrated mass flow and temperature measurement
* Good repeatability
* Supports multiple gas measurements
* Standard Modbus RTU communication
* 2 NPN open collector outputs (for upper and lower limit alarms)
* TFT screen display (supports four display direction settings: up, down, left, and right)
* 9~28V DC power supply

Specification:

Connection	RC3/4 (G3/4 male thread)
Power Supply	9–28V DC
Power Consumption	<0.85W
Operating Pressure	0.1–1.5 MPa; maximum pressure resistance: 2.25 MPa
Operating Temperature	0–50°C
Calibration Reference	Air (25°C, 1 atm)

AMS3002H00 Thermal Gas Mass Flow Meter or Mass Flow Measurement Of clean Dry Gases
