Product Details:
|
| 316L Stainless Steel: | ISO Sensor Design | Calm Attitude: | Plus Or Minus 0.5% |
|---|---|---|---|
| Temperature Compensation: | 32°F ~ 158°F (0°C ~ 70°C) | Current Type: | Full Scale Output Typical Value Of 125mV |
| Voltage Type: | Full Scale Output Typical Value Of 75±1mV | Temperature Error Less Than: | 2% FSO |
| Two Standard Ranges: | 0 To 2.5 Psig (0 To 1 Bar), 0 To 5 Psig (0 To 17.24 Bar) | ||
| Highlight: | ISO Oil Filled Pressure Sensor,700Kpa Oil Filled Pressure Sensor |
||
Product Description:
NPI-19A-CZ701GH Oil Filled Core 700Kpa Pressure Sensor
Features:
The Nova Sensor NPI series combines solid-state integration with diaphragm isolation technology. The diffused silicon chip is encapsulated in an oil-filled chamber and isolated from the measurement medium by a stainless steel diaphragm and housing, providing a cost-effective product.
As with all Nova Sensor silicon pressure sensors, the NPI series uses Senstable piezoresistive Sensor technology and a temperature compensation process. The temperature compensation resistance loop is fabricated on a mixed ceramic substrate. The minimum temperature error of 0.75%(Max) is provided in the temperature compensation range of 0~70 ° C.
This SERIES CAN be widely used in the detection of gas and liquid pressure, based on the harsh environment, such as: sewage, steam, weak corrosive media, still have excellent performance.
The characteristics of
· Solid state, high reliability, high sensitivity
· 316 stainless steel diaphragm, compatible with corrosive media
· Pressure range: 0~700KPa
· Provide constant current and constant voltage power supply
application
· Liquid and gas pressure control system
· Automatic process detection and process control system
· Energy management, environmental protection and water treatment systems
· Ships and navigation systems
· Refrigeration and oxygen production equipment
· Diesel engine system
· Agricultural machinery and equipment
Specifications:
| Pressure range | 0~700KPa /Psi |
| A load | 2X |
| Heavy volume |
Material 10 (type A) Material is 45 (B/H/J) |
| "O" ring size | Phi x 0.99 16.76 mm |
| Working temperature | - 40 ~ 125℃ |
