Miniature Low Pressure Flow-Through Sensors
The 26PC Series Miniature Low Pressure Flow-Through Sensors feature proven sensing technology that uses a specialized
piezoresistive micromachined sensing element to offer high performance, reliability, and accuracy.
Each sensor contains four active piezoresistive elements in a Wheatstone bridge configuration. When pressure is applied,
the resistance changes and provides an output signal in mV proportional to the input pressure.
The low power, compensated, unamplified Wheatstone bridge circuit design offers 1 psi through 100 psi sensing ranges
in a variety of pressure port types and termination configurations. The mV output is available in both negative and positive
voltage.
Visit www.honeywell.com/sensing to download 3D CAD drawings in IGES and STEP format, and 2D drawings in PDF
format.
These sensors are intended for use with media compatible with plastics and media seals specified in the Nomenclature
and Order Guide (see Figure 2). (2D drawings also provide plastic housing and port material information.) They are designed
and manufactured according to ISO 9001 standards.

Specification:
