YJJ 26PCCFD2G 15 Psi Miniature Pressure Sensor Is Used In Medical Devices

Product Description:

YJJ 26PCCFD2G 15 Psi Miniature Pressure Sensor Is Used In Medical Devices

Features:

26PC series miniature pressure sensors are compact and cost-effective devices, suitable for both wet and dry media. These sensors employ proven sensing technology and utilize specialized piezoresistive micro-machined sensing elements, offering high performance, reliability, and accuracy. Each sensor contains four active piezoresistors, forming a Wheatstone bridge. When pressure is applied, the resistance changes, and the sensor provides a millivolt output signal proportional to the input pressure. The low-power 26PC sensors are designed to accommodate pressures ranging from 1 psi to 250 psi and have an operating temperature range of -40°C to 85°C (-40°F to 185°F). These sensors can accommodate a variety of wet and dry media compatible with polyamide (PPA) plastics and the sealing media specified in the naming convention and order guidelines (see Figure 2). The 26PC sensors comply with the RoHS standard. Their design and manufacture adhere to the ISO 9001 standard. What makes our sensors better. Wet/wet capability (i.e., liquid on both ports) Selectable sealing elements that match the used medium Differential application of higher pressure range Multiple pressure port types

Features and advantages One sensor can perform two tasks! Provides liquid sensing in differential applications Temperature range of -40°C to 85°C allows for use in various environmental conditions Pressure range of 1 psi to 250 psi provides flexibility for customers' pneumatic designs Differential and gauge pressure measurement types allow customers to choose the sensor suitable for their application

Potential applications

Medical Oxygen concentration meter: Can be used to measure the pressure of the sieve bed to optimize system performance Dental chair: Can be used to control the air pressure in various dental instruments. Blood dialysis: Can be used to monitor the correct pressure to help ensure optimal blood filtration Respirator: Can be used to measure exhalation pressure to ensure correct respiratory analysis. Industrial Water control valve: Can be used to monitor water usage in homes and buildings. Irrigation equipment: Can be used to control water pressure and flow in delivery. Filter monitoring: Can be used to detect if the filter is clogged and requires replacement. Pressure valve: Can be used to measure and control pressure in industrial processes. Air compressor: Can be used to control the pressure supplied to end-user equipment.

Specifications:
